Product

1

Dimension

L3600*W1360*H1500mm

2

General power

About 72kw

3

Control mode

Touch screen + PLC control

4

material

Corrosion-resistant imported PP material

5

Belt material

Stainless steel SUS 316

6

Power supply

3PH, 380 VAC, 5 wires

7

Weight

About 1200kg

8

DI water  requirement

>15MΩ

9

DI water inflow requirement

1.5 m3/h

10

 Exhaust requirement

1200 CFM

11

Noise

< 70 Db

12

Transport speed

0mm/min-1600mm/min

13

Spraying pressure of the chemical washing area

25-35psi

14

Spraying pressure of the DI washing area

30-40psi

15

Product thickness

0-60mm

16

Product weight

Less than 10kg

17

Temperature of water tank of the chemical water section

25-75℃

18

Angle of air knife

Adjustable angle and lifting

19

Installation way of spryer nozzle

Quick connection mode for the convenience of changing

20

Belt width

500mm, customized

21

Automatic liquid adding system (calculating pieces, time and quantity and replenish)

(optional)

22

Installation mode of water pipe

Rapid connection and convenient maintenance

23

Filter precision (grade two)

100u
